Talon Mark is a high-performance industrial laser engineered for ultra-high-speed on-the-fly marking and coding applications in the Food & Beverage industry. Its broad operating range makes it ideal for demanding environments where extended production cycles depend on consistent beam quality and maximum uptime. Key features such as advanced pulse control for first-pulse suppression, pulse-on-demand, and pulse-synchronized output deliver superior process control and consistently precise marking results.
Applications
APPLICATIONS
- Laser Marking and Coding for Food & Beverage
- Ultra-High-Speed Marking and On-The-Fly-Marking (MOTF) for Packaging
- Precision Marking in Medical and Life, Health, and Science
Specifications
Output Characteristics1
| Talon Mark UV15 | Talon Mark UV20 | |
|---|---|---|
| Wavelength | 355 nm | 355 nm |
| Power | >15 W @ 50 kHz | >20 W @ 50 kHz |
| Pulse Energy | >300 µJ | >400 µJ |
| Repetition Rate | up to 150 kHz | up to 150 kHz |
| Pulse Width | <28 ns @ 50 kHz | <28 ns @ 50 kHz |
| Pulse-to-Pulse Energy Stability2 | <2% rms @ 50 kHz | <2% rms @ 50 kHz |
Beam Characteristics2
| Talon Mark | |
|---|---|
| Spatial Mode | TEM00 |
| M2 | <1.2 |
| Polarization Ratio | >100:1 vertical |
| Beam Diameter | 2.0 mm collimated |
| Beam Divergence (full angle) | <0.3 mrad |
| Beam Circularity | >90% |
Operating Conditions / Environmental Range
| Talon Mark | |
|---|---|
| Input Voltage | 48 VDC |
| Warm-up Time (typical) | <40 min from standby; <60 min from cold start |
| Temperature Range | 18 to 35°C operating; -20 to 50°C non-operating |
| Humidity | 8–95% non-condensing |
| Coolant Set Temperture | 20-25°C |
| Total Power Consumption | <300 Watts |
Physical Characteristics
| Talon Mark | |
|---|---|
| Dimensions (Laser) (L x W x H)4 | 620 x 153 x 102 mm |
| Weight (Laser) | 11.5 kg |
Features
| Talon Mark | |
|---|---|
| Integration Ready | Integration and installation ready, compatible with most scanners and timing control cards |
| Pulse Energy Control | Advanced pulse control modes for on-the-fly precision marking including First Pulse Suppression, Pulse-on-demand (POD), Pulse-synchronized-Output (PSO) |
| CW Alignment Beam Mode | Lower power CW UV beam for easy and secure alignment and guidance |
| Internal Power Monitor | Integrated power sensor for real time power monitoring |
| Sacrificial Window | Customer accessible and field replaceable output window for long system lifetime in harsh environments |
Footnotes:
- Due to our continuous product improvement, all specifications are subject to change without notice.
- All beam parameter specifications are at 50 kHz.
- The Talon Mark is a Class IV – High Power Laser, whose beam is, by definition, a safety and fire hazard. Take precautions to prevent exposure to the direct and reflected beams. Diffuse as well as specular reflections can cause severe skin or eye damage.
Features
Unprecedented Combination of Performance, Reliability and Cost
Expanding on the proven success of the Talon family of UV and green Q-switched lasers, Talon Mark offers an unmatched blend of performance, reliability, and cost-efficiency. Leveraging Spectra-Physics’ proprietary It’s in the Box™ architecture which integrates the laser and controller into a single, compact unit. Talon Mark delivers over 20 W of UV power and greater than 400 μJ per pulse, with exceptional pulse-to-pulse stability and high-quality TEM00 mode, sustained over tens of thousands of operating hours.
User-Friendly and High Reliability
Designed for seamless integration, Talon Mark comes in a ready-to-install package that simplifies implementation into manufacturing tools. All Talon lasers are boresighted,
making any necessary replacements quick and hassle-free. Remote control is supported via RS-232 or USB interfaces, while onboard electronics feature extensive data logging capabilities. With stable mode quality across its full operating range and robust design elements including long-life diodes and innovative optical and electronics engineering, Talon Mark is built for continuous, 24/7 high-speed precision marking in even the most demanding environments.
Compatible Power Sensors
To verify and analyze the output power of your Talon Mark laser, we recommend the Ophir F80(120)A-CM-17 (7Z07103) or 30(150)A-SV-17 (7Z02724) thermal power sensor and Centauri laser power meter. Additional information on this laser measurement equipment can be found on the ophiropt.com website. Other Ophir sensors and meters may also be suitable for the Talon Mark, depending on application. Ophir also works with laser system developers to achieve embedded beam diagnostics to monitor system performance as an OEM solution.
